The I.MX 8M Plus family focuses on machine learning and vision, advanced multimedia, and industrial automation with high reliability. It is built to meet the needs of Smart Home, Building, City and Industry 4.0 applications.
Features
Multicore Processing and Memory Interfaces
| Feature | Specification |
|---|
| Cortex-A53 | 4x or 2x up to 1.8 GHz |
| Cortex-M7 | up to 800 MHz |
| DDR4/LPDDR4 | 32-bit up to 4.0GT/s |
Machine Learning and Vision
| Feature | Specification |
|---|
| Neural Processing Unit (NPU) | Up to 2.3 TOPS |
| Dual Image Signal Processor (ISPs) | Resolution up to 12MP and input rate up to 375MPixels/s |
| Camera Interface | 2x MIPI CSI |
| Capability | Specification |
|---|
| Video Decode | 1080p60, h.265/4, VP9, VP8 |
| Video Encode | 1080p60, h.265/4 |
| GPU | 16 GFLOPS (high-precision) OpenGL® ES 3.1/3.0, Vulkan®, Open CL™ 1.2 FP, OpenVG™ 1.1 |
| Audio | 18x I2S TDM, DSD512, S/PDIF Tx + Rx, 8-ch PDM Mic input, eARC, ASRC |
| Display | MIPI-DSI, HDMI 2.0a Tx, LVDS (4/8-lane) Tx |
High Speed Interfaces
| Interface | Specification |
|---|
| Gigabit Ethernet | 2x with AVB, IEEE 1588, EEE and 1x w/ TSN |
| USB | 2x USB 3.0/2.0 Dual-Role with PHY type C |
| PCIe | Gen 3 |
| SDIO | 3x SDIO 3.0 |
| CAN FD | 2x |
Industrial Reliability
| Feature | Specification |
|---|
| DDR Inline ECC | for LPDDR4 and DDR4 |
| Process | 14 FinFET with low soft error rate (SER) |
Operating Systems
| OS | Version/Name |
|---|
| Linux® | - |
| Android® | - |
| Windows 10 | IoT Enterprise |
| FreeRTOS | - |
Package and Temperature
| Category | Specification |
|---|
| Package | FCBGA, 15x15 0.5 mm pitch |
| Temperature Range | Consumer (0 °C to 95 °C Tj) / Industrial (-40 °C to 105 °C Tj) |
For more information, please check the i.MX 8M Plus data sheet.
