Bit-Brick PI ONE Hardware Introduction

Published May 2024

NOTE​

BIT-BRICK IS THE TRADEMARK OF BIT BRICK LTD. ANYONE WANT TO USE THIS SHOULD GET THE PERMISSION FROM BIT BRICK COMPANY.

Overview​

Welcome to PI ONE: an interesting single board computer.

Specification​

  • Processor:

    • Quad Cortex®-A53 processors operation up to 1.6 GHz
    • Cortex®-M7 CPU operating up to 800 MHz
    • Cortex®-A53 MPCore TrustZone® support

  • Features:

    • GC7000UL GPU, Supports OpenGL ES 1.1, 2.0, 3.0, OpenCL 1.2, Vulkan
    • LPDDR4 SDRAM (2GB and 4GB available)
    • HDMI 2.0a, Resolution up to 3840 x 2160p30
    • 2×USB 3.0 ports
    • microSD card slot
    • 2×Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT)
    • 2×4-lane MIPI camera/display transceivers
    • PCIe 2.0 x1 interface for fast peripherals
    • Power and reset key support
    • Power LED, and 2 programmable LED support
    • 3.5mm headset interface
    • 5V/5A DC power via USB-C
    • USB to serial support, type C interface
    • 40 pin connector, support CAN/UART/SPI/I2C/PWM/I2S etc.
    • WIFI/Bluetooth OPTIONAL (M.2 slot support SDIO WIFI module)

  • Production lifetime: PI ONE will remain in mass production until 2035.

  • Compliance: For a full list of local and regional product approvals, please visit pip.bit-brick.com.

Physical specification​

(The physical specification details are not provided in the given content.)
